ALSYNITE ULTRA COOL adalah lembaran Fibre Reinforced Polyester (FRP) berkualitas tinggi dengan keunggulan mengatur panas sinar matahari yang masuk.
ALSYNITE ULTRA COOL menyediakan
sarana ekonomis untuk transmisi cahaya alami yang disebarkan ke
interior bangunan, pada saat bersamaan memantulkan panas matahari yang
tidak perlu , menghasilkan penghematan biaya yang cukup besar untuk
penerangan dan pendingin ruangan.
Dilengkapi dengan Film Performa Tinggi A15, bersama dengan Sistem Polyester Resin termutakhir kami.
Alsynite Ultra Cool adalah
lembar kaca kualitas premium Reinforced Polyester (GRP) yang
mentransmisikan cahaya alami serta mengendalikan transmisi panas
matahari.
Fitur Utama
- Sifat difusi cahaya yang baik
- Refleksi panas matahari tahan lama
- Penghematan besar dalam biaya energi
- Karakteristik pelapukan yang sangat baik dalam jangka panjang
- Unik untuk Alsynite Ultra Cool adalah Ultra Putih dilaminasi lapisan film bawah khas
- Tetap bening dalam waktu yang lama
- Resistensi erosi permukaan yang luar biasa
- Teknologi Non delaminating surface
- 25 Tahun Garansi - Ketentuan Berlaku
- Tersedia dalam lebih dari 140 profil
DEMAND THEBEST – DEMAND A15 FILM
Alsynite hanya memilih film pelindung A15 dan pelapis dalam pembuatan berbagai produk atap berkualitas
Tidak ada pengganti untuk kualitas. Silakan bandingkan dengan produk roofing sejenis ketika membandingkan.
A15 film adalah inovator terkemuka dalam teknologi film pelindung dan Alsynite tidak akan menggunakan film pelindung selain A15.
Product Description
ALSYNITE ULTRA-COOL is a premium quality Fibre Reinforced Polyester (FRP) sheet
with all the qualities of ALSYNITE ULTRA but with the added advantages
of controlled solar heat transmission. It is identified by its ultra
white finish.
ALSYNITE ULTRA-COOL provides
an economical means of transmitting diffused natural light to the
building interior, whilst at the same time reflecting unnecessary solar
heat, resulting in substantial cost savings in lighting and cooling
expenses.
ALSYNITE ULTRA COOL menyediakan
sarana ekonomis untuk transmisi cahaya alami yang disebarkan ke
interior bangunan, pada saat bersamaan memantulkan panas matahari yang
tidak perlu , menghasilkan penghematan biaya yang cukup besar untuk
penerangan dan pendingin ruangan.
Dilengkapi dengan Film Performa Tinggi A15, bersama dengan Sistem Polyester Resin termutakhir kami.
Alsynite Ultra Cool adalah
lembar kaca kualitas premium Reinforced Polyester (GRP) yang
mentransmisikan cahaya alami serta mengendalikan transmisi panas
matahari.
Fitur Utama
- Sifat difusi cahaya yang baik
- Refleksi panas matahari tahan lama
- Penghematan besar dalam biaya energi
- Karakteristik pelapukan yang sangat baik dalam jangka panjang
- Unik untuk Alsynite Ultra Cool adalah Ultra Putih dilaminasi lapisan film bawah khas
- Tetap bening dalam waktu yang lama
- Resistensi erosi permukaan yang luar biasa
- Teknologi Non delaminating surface
- 25 Tahun Garansi - Ketentuan Berlaku
- Tersedia dalam lebih dari 140 profil
DEMAND THEBEST – DEMAND A15 FILM
Alsynite hanya memilih film pelindung A15 dan pelapis dalam pembuatan berbagai produk atap berkualitas
Tidak ada pengganti untuk kualitas. Silakan bandingkan dengan produk roofing sejenis ketika membandingkan.
A15 film adalah inovator terkemuka dalam teknologi film pelindung dan Alsynite tidak akan menggunakan film pelindung selain A15.
Product Description
ALSYNITE ULTRA-COOL is a premium quality Fibre Reinforced Polyester (FRP) sheet
with all the qualities of ALSYNITE ULTRA but with the added advantages
of controlled solar heat transmission. It is identified by its ultra
white finish.
ALSYNITE ULTRA-COOL provides
an economical means of transmitting diffused natural light to the
building interior, whilst at the same time reflecting unnecessary solar
heat, resulting in substantial cost savings in lighting and cooling
expenses.
Key Features
- Excellent long term weathering characteristics
- Superior 25 Year warranty *conditions apply
- Non delaminating surface technology
- Resistant to degradation and embrittlement
- Outstanding surface erosion resistance
- Resistant to commonplace chemicals
- Superior long term diffused light properties
- Superior long term reduction of solar heat
- Provides substantial savings in energy costs
- Excellent long term weathering characteristics
- Superior 25 Year warranty *conditions apply
- Non delaminating surface technology
- Resistant to degradation and embrittlement
- Outstanding surface erosion resistance
- Resistant to commonplace chemicals
- Superior long term diffused light properties
- Superior long term reduction of solar heat
- Provides substantial savings in energy costs
Typical Applications
- Industrial and commercial skylights
- Building skylight sidings
- Nursery & retail areas
- Sports venues and shopping centre skylights
- Light diffusers
- Any building or structure requiring diffused light with minimum heat transmission
- Industrial and commercial skylights
- Building skylight sidings
- Nursery & retail areas
- Sports venues and shopping centre skylights
- Light diffusers
- Any building or structure requiring diffused light with minimum heat transmission
Product Specifications
Profiles
Due
to Alsynite’s global presence, we have an extensive range of profiles
within our portfolio that matches most metal sheet profiles.
Sheet Length
Standard sheet lengths up to 11.9 meters.
Other non-standard lengths are available subject to special order and shipping parameters.
Weights
- 1800 gsm
- 2400 gsm
- 3050 gsm
- 3660 gsm
- 4880 gsm
The
standard weight for industrial applications is 2400 gsm. For sheet
weights not listed, please contact your nearest Alsynite distributor for
further details.
Nominal Thickness
TBA
Surface Coating
World renowned improved UV protection film, and Ultra White film. 20 micron nominal thickness.
Colors
Only available in ultra white finish.
Resin System
Advanced general purpose grade orthophthalic polyester.
Reinforcement
“E” Class Fibre optic glass, at least 22%
Light Transmission
36% (Using 2400 gsm 1.5mm sheet)
Thermal Conductivity
Heat Distortion Temperature
+180 to 200
Thermal Expansion
2.5 x 10-5 cm/cm/°C
UV Resistance
100%
Profiles
|
Due
to Alsynite’s global presence, we have an extensive range of profiles
within our portfolio that matches most metal sheet profiles.
|
|---|---|
Sheet Length
|
Standard sheet lengths up to 11.9 meters.
Other non-standard lengths are available subject to special order and shipping parameters.
|
Weights
|
The
standard weight for industrial applications is 2400 gsm. For sheet
weights not listed, please contact your nearest Alsynite distributor for
further details.
|
Nominal Thickness
|
TBA
|
Surface Coating
|
World renowned improved UV protection film, and Ultra White film. 20 micron nominal thickness.
|
Colors
|
Only available in ultra white finish.
|
Resin System
|
Advanced general purpose grade orthophthalic polyester.
|
Reinforcement
|
“E” Class Fibre optic glass, at least 22%
|
Light Transmission
|
36% (Using 2400 gsm 1.5mm sheet)
|
Thermal Conductivity
| |
Heat Distortion Temperature
|
+180 to 200
|
Thermal Expansion
|
2.5 x 10-5 cm/cm/°C
|
UV Resistance
|
100%
|
Mechanical Properties
PROPERTIES
Flexural Strength
Tensile Strength
Shear Strength
TEST VALUE
177MPa
94MPa
90MPa
PROPERTIES
Specific Gravity
Compressive Strength
Barcol Hardness
TEST VALUE
1.41g/cm3
135MPa
> 50
PROPERTIES
|
Flexural Strength
|
Tensile Strength
|
Shear Strength
|
|---|---|---|---|
TEST VALUE
|
177MPa
|
94MPa
|
90MPa
|
PROPERTIES
|
Specific Gravity
|
Compressive Strength
|
Barcol Hardness
|
TEST VALUE
|
1.41g/cm3
|
135MPa
|
> 50
|
Physical Properties
PROPERTIES
Specific Gravity
(gm/cc)
Thermal Expansion
(10-5cm/cm/°C)
Water Absorption
(%)
TEST VALUE
1.41
2.2
0.52 to 0.60
PROPERTIES
Thermal Conductivity
(W/m°K)
Heat Distortion Temperature (°C)
Operating Temperatures (°C)
TEST VALUE
0.158
+180 to 200
-20 to +95
PROPERTIES
|
Specific Gravity
(gm/cc) |
Thermal Expansion
(10-5cm/cm/°C) |
Water Absorption
(%) |
|---|---|---|---|
TEST VALUE
|
1.41
|
2.2
|
0.52 to 0.60
|
PROPERTIES
|
Thermal Conductivity
(W/m°K) |
Heat Distortion Temperature (°C)
|
Operating Temperatures (°C)
|
TEST VALUE
|
0.158
|
+180 to 200
|
-20 to +95
|
Solar Optical Properties
PROPERTIES
Solar Transmittance
Luminous Transmittance
Diffused Light Transmission (%)
ULTRA-WHITE
0.22
0.18
36
PROPERTIES
Shading Coefficient
U-Value (W/m2K)
Solar Heat Gain (W/m2)
ULTRA-WHITE
0.33
5.7
227
PROPERTIES
Solar Heat Gain Coefficient
Transmittance 380-320nm (UV – A)
Transmittance 320-280nm (UV – B)
ULTRA-WHITE
0.29
-
-
Results of tests are based on a 2400 gsm sheet.
